SG - Three-phase dry-type transformer

Get a Quote

SG Series

SG - Three-phase dry-type transformer

Suitable for AC 50Hz circuits, serving as control power for machine tools, mechanical equipment, low-voltage switchgear, and electrical drive control equipment; also suitable as a small power source. Complies with.
BuildingIndustrial
  • Core parameters
  • Standard: Q/ZT 525.
  • Overall efficiency: ≥95%
  • SVG(kvar): 50/100
  • Dynamic response time: ≤100us
    • Get a Quote

    Product Details

    Learn more about our products

    Product Model Three-Phase Dry-Type Transformer
    Rated Capacity 340000 kVA
    Rated Voltage Ratio （1100/√3/-4×1.25%）/27 kV
    Short-Circuit Impedance 14 %
    Rated Frequency 50 Hz
    Connection Group Designation YND11
    Insulation Level S/1800L/2250AC1100 （5min）
    LI325AC140/LI200AC85 kV
    Cooling Method ODAF
    No-Load Loss 148 kW
    Load Loss 728 kW
    Temperature Rise Limit Top layer oil: 50K | Average winding oil: 60K
    Noise (Sound Pressure Level) ≤75 dB(A)

    * For specific product requests, please contact us for customized solutions to your needs.
